Product features
Hansgrohe Croma 160 Showerpipe Set
consists of:
Hansgrohe Ecostat Comfort Thermostat
- safety stop at 40C to protect against accidentally hot temperatures (scalding protection)
- adjustable hot water limitation
- outlets controlled via volume control/diverter and cannot be used simultaneously
- exposed design allows easy installation, all working parts are outside of the wall
- 1/2″ connection thread
- centre distance 150 mm12 mm
Hansgrohe Croma 160 Overhead Shower with Arm
- spray mode: Rain (powerful, pattering rain jet, ideal for washing hair)
- maximum flow rate: Rain (at 3 bar): 17 litres per minute
- operating pressure: min. 1 bar / max. 6 bar
- fully chrome-plated, plastic spray face
- 1/2″ connection thread
- with swivel joint
Hansgrohe Croma 100 Vario Hand Shower
- 4 spray modes: Rain (powerful, pattering rain jet), normal spray (extensive, rich jet), Shampoo spray (powerful jet to wash your hair), Massage (konzentrierter, pulsierender Wasserstrahl)
- spray mode adjustment by turning
- maximum flow rate (at 3 bar): 18 litres per minute
- operating pressure: min. 1 bar / max. 6 bar
- shower head size: 100 mm
- with internal water conduction
- rinseable dirt filter
- 1/2″ connection thread
Hansgrohe Isiflex Shower Hose, 1.60 m
- high-quality metal effect shower hose
- anti-microbial coating to reduce the presence of bacteria
- shower hose length: 1600 mm
- pivot connectors prevent hose from tangling
- kink-protected
- larger inner diameter of 8 mm for higher flow rates
- conical nuts at both ends
Please note
- According to DIN 18534, areas behind fittings must be protected from moisture damage. Use special sealing tapes to ensure proper sealing. Please order separately. You will find suitable sealing tapes under accessories.
SpecificationsItem number:27135000Series:CromaMaterial:metal/plasticColour:chromeMaterial overhead shower:plasticShower hose length (mm):1600Height (mm):1101Hand shower length (mm):237Diameter of hand shower (mm):100Projection (mm):285Diameter of overhead shower (mm):160Type of fitting:thermostatsType of installation:exposedType of overhead shower assembly:integratedShape:roundWater activation:by rotatingMax. water consumption of the hand shower at 3 bar (l/min):18Max. water consumption of the overhead shower at 3 bar (l/min):17Components:with tap fittingOverhead shower spray modes:1 jetHand shower spray modes:4 jetsBath filler:without bath fillerShippingContains:exposed shower thermostat, overhead shower, shower arm, shower rail, hand shower, shower hose, glider, set of fittingsPackaging type:ParcelpdfProduct data sheetpdfAssembly instructionspdfCare instructions
