Consisting of three components: the Axor Edge three-hole bath mixer
Enhance your bath area in no time at all with the Axor Edge three-hole bath mixer. It consists of three components.
With bath spout, hand shower and diverter
An angular look, a design that has it all, an all-round carefree package, so to speak – that is the Edge three-hole bath mixer from Axor. Look forward to the bath spout that fills your bath evenly with the full, airy jet of water. You can also conveniently switch back and forth between the two sprays and activate the hand shower at the same time using the diverter. The hand shower, in turn, features QuickClean technology, which ensures that even limescale deposits can be removed in no time at all with a light wipe. Fully relax in the bath with bathroom mixers from the Edge series by Axor!
Product features
Bath Spout
- 1 spray mode: normal spray (extensive, rich jet)
- aerator for a well-shaped jet
- soothing full, soft water jet enriched with air (AirPower)
Single Lever Mixer and Diverter
- suitable for 2 outlets
- smooth ceramic cartridge
- adjustable temperature limiter
- activate the hand shower via diverter
Hand Shower with Shower Bracket, Shower Hose and sBox Hose Roll System
- 2 spray modes: Rain (powerful, pattering rain jet, ideal for washing hair), MonoRain (exceptional, soothing relaxation jet)
- switch spray mode by rotating the shower head
- limescale can be removed from the silicone naps with a simple wipe (QuickClean)
- hand shower length: 190 mm
- all-in-one-system for pulling out and retracting the hand shower
- sBox for quiet, smooth-running and protected hose guide
- includes shower bracket for fixed, vertical installation of the hand shower
- easy use, requires little pulling & holding force
- hose is kink resistant, flexible and with anti-twist protection
- synthetic sheathed shower hose pull-out length: 1450 mm
- space-saving installation
- size of hose roll system: W: 191 H: 515 D: 48 mm
- can be removed easily for cleaning and maintenance
- intrinsically safe against backflow
Please note
- please order concealed installation unit separately. This can be found in Accessories
- the bath rim must be at least 100 mm wide
- according to the manufacturer, suitable for instantaneous water heaters
SpecificationsItem number:46430000Series:EdgeDesigner:Jean-Marie MassaudMaterial:brassColour:chromeShower hose length (mm):1450Hand shower length (mm):190Projection (mm):210Type of fitting:single lever mixersType of installation:deck-mounted for bathsShape:square/rectangularWater activation:by lifting/tiltingMax. water consumption of the bath inlet at 3 bar (l/min):20Max. water consumption of the hand shower at 3 bar (l/min):9Spout:jetComponents:without shower railNo. of outlets:2 outletsHandle postion:rightBath filler:with bath fillerShippingContains:
fitting, hand shower, shower bracket, shower hose, hose box, cover
Packaging type:ParcelpdfProduct data sheetpdfTechnical drawings
